1
6
GB
Installing the safety glass
Mount the safety glass on the guard hood as
illustrated.
2
230 V ~50 Hz; IP 23
P
1 400 W S2 30 min LPA: 77,5 dB(A) LWA: 90,5 dB(A)
2800 min
-1
134 min
-1
Ø 150 x 20 x Ø 32 mm ø 200 x 40 x Ø 20 mm
21,98 m/s 1,40 m/s
Technical data
Layout
1 ON/OFF switch
2 Glass guard
3 Spark deflector
4 Hood guard
5 Grinding wheel
6 Fixing screw for the workpiece
support
7 Workpiece support
8 Wet grinding wheel
9 Water tank
