EINHELL RT-JS 85 User Manual

 Important!
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety regulations with due care. Keep this manual in
a safe place, so that the information is available at all
times. If you give the equipment to any other person,
hand over these operating instructions and safety
regulations as well. We cannot accept any liability for
damage or accidents which arise due to a failure to
follow these instructions and the safety instructions.
1. Safety information
Please refer to the booklet included in delivery for the
safety instructions.
 CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1)
1. Knurled screw for speed control
2. Locking button
3. ON/OFF switch
4. Holder for saw blades
5. Power cable
6. Adapter for dust extraction system
7. Adjustable soleplate
8. Selector switch for pendulum action
9. Dial scale for soleplate
10. Guide roller
11. Parallel stop
12. Saw blade
13. Locking screws for parallel stop
14. Blade holder
15. Safety guard
16. LED lamp
17. ON/OFF switch for LED lamp
18. Locking screw for soleplate
3. Proper use
The jigsaw is designed for sawing wood, iron, non-
ferrous metals and plastics using the appropriate saw
blades.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains voltage: 230 V~ 50 Hz
Power input: 750 W
Stroke speed: 800 – 3,000 min
-1
Stroke height: 23 mm
Cutting depth, wood: 85 mm
Cutting depth, plastic: 12 mm
Cutting depth, iron: 8 mm
Miter cut: up to 45° (left and right)
Protection class: II / 쓑
Weight: 2.5 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L
pA
sound pressure level 87,3 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 98,3 dB(A)
K
WA
uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
7
GB
Anleitung RT-JS 85_SPK1:_ 15.09.2008 12:49 Uhr Seite 12

EINHELL RT-JS 85 Specifications

General

Stroke height	23 mm
No-load stroke rate	3000 spm
Input power	750 W
Power source	AC
AC input voltage	230 V
Cutting depth in wood	85 mm
Product color	Grey, Red
Bevel adjustment	Yes
Bevel capacity (max)	45 °

Weight and Dimensions

Depth	445 mm
Width	135 mm
Height	300 mm
Weight	2500 g
