17
GB
intervals. Use a standard, acid-free lubricating
grease to do this.
Caution: Do not use your household refuse bin as a
receptacle for oil and grease-soaked cleaning rags or
grease and oil sludge. Dispose of these toxic
materials in an environmentally-friendly fashion.
Regularly check and clean the ventilation holes.
Store the device in a dry room. Should the device
become damaged, do not try to repair it yourself;
leave this work to the hands of a qualified electrical
technician.
8.0. Ordering replacement parts
Replacement parts can be ordered through ISC
GmbH (see the warranty declaration for the
address). The following information should be
provided when placing an order:
Model/type of device
Item number of device
I.D. number of device
Number of the required replacement part
9.0. Technical data SB 701/1 SB 1020/1W SB 1020/1D SB 1625/1W SB 1625/1 D
Nominal input voltage 230V ~/ 50 Hz 230V ~/ 50 Hz 400V ~/ 50 Hz 230V ~/ 50 Hz 400V ~/ 50 Hz
Power rating 630 Watt 700 Watt 700 Watt 700 Watt 700 Watt
Operating mode S2 15 min. S2 15 min. S2 15 min. S2 15 min. S2 15 min.
Motor speed 1400 min
-1
1400 min
-1
1400 min
-1
1400 min
-1
1400 min
-1
Output speed 220 - 2.450 min
-1 -1 -1 -1 -1
Speed levels 12 12 12 12 12
Drill chuck mount B 16 B 16 B 16 B 16 B 16
Scroll chuck Ø 3 - 16 mm Ø 3 - 16 mm Ø 3 - 16 mm Ø 3 - 16 mm Ø 3 - 16 mm
Max. shaft diameter 16 mm 16 mm 16 mm 16 mm 16 mm
Throat 126 mm 169 mm 169 mm 169 mm 169 mm
Dimensions of drill table 200 x 195 cm 260 x 260 mm 260 x 260 mm 260 x 260 mm 260 x 260 mm
Angle adjustment of tabel 45° / 0° / 45° 45° / 0° / 45° 45° / 0° / 45° 45° / 0° / 45° 45° / 0° / 45°
Drill depth 60 mm 80 mm 80 mm 80 mm 80 mm
Diameter of pillar 60 mm 70 mm 70 mm 70 mm 70 mm
Height ca. 850 mm ca. 1010 mm ca. 1010 mm ca. 1590 mm ca. 1590 mm
Foot print 350 x 230 cm 405 x 240 mm 405 x 240 mm 450 x 265 mm 450 x 265 mm
Weight 33,5 kg 52,5 kg 52,5 kg 60 kg 60 kg
LPA sound pressure level 61,5 dB(A) 61,5 dB(A) 61,5 dB(A) 61,5 dB(A) 61,5 dB(A)
LWA sound power level 74,5 dB(A) 74,5 dB(A) 74,5 dB(A) 74,5 dB(A) 74,5 dB(A)
