Insert the batteries (b), ensuring that you fit them the right way round.
Close the battery compartment cover (6) again, making sure that it locks securely
If the LED indicator flashes red continuously even though the device is upright, this means that the batteries are
flat. Replace them as described above.
Using the universal clamp (Fig. 3/Item 8)
You can fasten the supplied universal clamp (8) to a table, shelf or similar object by clamping it in position. To fit the
equipment to the universal clamp, proceed as follows:
Place the equipment by the female thread (7)on the base of the equipment onto the male thread (10) of the
universal clamp (8)
Screw the equipment to the mounting with the help of the wheel
Using the adjusting screw (9) and the ball joints (a), you can tilt the equipment to the angle you require
To disassemble, proceed in reverse order
Operation
Switching On/Off (Fig. 1)
Switching on:
Place the laser on a flat surface or fit it to the universal clamp and fasten it as described in 5.2.
To switch the laser on, push the On/Off switch to the left (viewed from the front). The lasers switch on, the green
LED (4) comes on and the pendulum will no longer be blocked, which means the laser can be aligned.
Press the button (5) to display or hide the vertical or horizontal lines again individually.
Switching off: To switch off, push the On/Off switch back to the position on the right (viewed from the front). The
lasers which off and the pendulum will be blocked.
Important! To prevent damage during transport or storage, the equipment must always be switched off as described
above.
Automatic alignment of the laser (Fig. 4)
After the laser has been switched on with the On/Off switch (1), the lasers are aligned automatically by the pendulum
so that the vertical and horizontal lines are displayed level on the wall. (See Fig. 4)
Press the button (5) to display or hide the vertical or horizontal line individually.
Important!
Make sure that the equipment is never tilted more than 4 degrees or stands at an angle. If this is the case,
the laser beams will fl ash and the LED (4) will light up red.
Manual alignment of the laser (Fig. 5)
The laser can also be aligned manually, to enable a diagonal line to be displayed. Proceed as follows:
Place the laser on a flat surface or fit it to the universal clamp and fasten it as described in 5.2.
To switch the equipment on, push the On/Off switch (1) to the left (viewed from the front).
Wait until the lasers are aligned and then move the On/Off switch (1) back to the right.
Now press the button (5). The lasers switch on and the LED (4) lights up red, because the pendulum is
blocked.
Now you can tilt the laser to the angle you require so that the lines are displayed diagonally on the wall. (See
Fig. 5)
Press the button (5) to hide or display the vertical or horizontal line individually or to switch the equipment off
again.
Cleaning, maintenance, and ordering spare parts
Cleaning
Keep all safety devices, air vents, and the motor housing free of dirt and dust as far as possible. Wipe the
equipment with a clean cloth or blow it down with compressed air at low pressure.
We recommend cleaning the equipment immediately each time after use.
Clean the equipment regularly with a damp cloth and some soft soap. Do not use cleaning agents or solvents;
