Benefits:
n The drill bit is easier to control when starting the
hole and will not slide away.
n You avoid drilling messy holes (for example in
tiles).
6.3 Clockwise/Counter-clockwise switch
(Fig. 6/Item 7)
n Change switch position only when the drill is
at a standstill!
n Switch the direction of the hammer drill using the
clockwise/counter-clockwise switch (7):
Direction Switch position
Clockwise (forwards and drill) Pushed in to the right
Counter-clockwise (reverse) Pushed in to the left
6.4 Drill / hammer drill selector switch
(Fig. 7/Item 3)
Change switch position only when the drill is at a
standstill!
Drill
Drill / hammer drill selector switch (3) in the drill
position. (Position A)
Use for: Wood, metal, plastic
Hammer drill
Drill / hammer drill selector switch (3) in the hammer
drill position. (Position B)
Use for: Concrete, rock, masonry
6.5 Tips for working with your hammer drill
6.5.1 Drilling concrete and masonry
n Switch the Drill/Hammer drill selector switch (3)
to position B (Hammer drill).
n Always use carbide drill bits and a high speed
setting for drilling into masonry and concrete.
6.5.2 Drilling steel
n Switch the drill / hammer drill selector switch (3)
to position A (drill).
n Always use HSS drill bits (HSS = high speed
steel) and a low speed setting for drilling steel.
n We recommend that you lubricate the hole with a
suitable cutting fluid to prevent unnecessary drill
bit wear.
6.5.3 Starting holes
If you wish to drill a deep hole in a hard material
(such as steel), we recommend that you start the
hole with a smaller drill bit.
6.5.4 Drilling tiles
n To start the hole, switch the drill / hammer drill
selector switch (3) to position A (drill).
n Switch the drill / hammer drill selector switch (3)
to position B (hammer drill) as soon as the drill
bit has passed through the tiles.
7. Replacing the power cable
If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
8. Cleaning and maintenance
Always pull out the mains power plug before starting
any cleaning work.
8.1 Cleaning
n Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
n We recommend that you clean the device
immediately each time you have finished using it.
n Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts of
the equipment. Ensure that no water can seep
into the device.
8.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important! The carbon brushes should not be rep
laced by anyone but a qualified electrician.
8.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
