6.9 Miter cuts (Fig. 9)
•
Set the angle on the soleplate (see section
5.4).
•
Observe the instructions in section 6.6.
•
Cut as shown in Fig. 9
6.10 LED lamp (Fig. 1/Item 18)
The LED lamp (18) can be used in poor lighting
conditions to additionally illuminate the cutting
position. Press the switch (17) to switch on. To
switch off , press the switch (17) again.
.
7. Replacing the power cable
Danger !
If the power cable for this equipment is damaged,
it must be replaced by a special power cable
which is available from the manufacturer or its
after-sales service.
8. Cleaning, maintenance and
ordering of spare parts
Danger !
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
8.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualifi ed electrician.
Danger! The carbon brushes should not be rep
laced by anyone but a qualifi ed electrician.
8.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
8.4 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
•
Type of machine
•
Article number of the machine
•
Identification number of the machine
•
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
9. Disposal and recycling
The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled. The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective equipment in
your household refuse. The equipment should
be taken to a suitable collection center for proper
disposal. If you do not know the whereabouts of
such a collection point, you should ask in your
local council offi ces.
10. Storage
Store the equipment and accessories out of
children’s reach in a dark and dry place at above
freezing temperature. The ideal storage tempe-
rature is between 5 and 30 °C. Store the electric
tool in its original packaging.
Anleitung_TE_JS_100_SPK9.indb 23Anleitung_TE_JS_100_SPK9.indb 23 17.05.2017 11:45:1317.05.2017 11:45:13

EINHELL TE-JS 100 Specifications

General

Stroke height	23 mm
No-load stroke rate	3000 spm
Input power	- W
Output power	750 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Cutting depth in wood	100 mm
Cutting depth in non-alloyed steel	10 mm
Soft grip	Yes
Product color	Black, Red
Bevel capacity (max)	45 °

Weight and Dimensions

Depth	415 mm
Height	310 mm
Weight	2300 g
