EIUK PTB 600 - Scope of Supply; Name; Technical Data

PTB600-MAN-V10.4 PTB 600 Instruction Manual
5
2 - SCOPE OF SUPPLY
2.1 - Name:
 Portable Temperature Calibrator PTB600, including accessories, as listed (reference to paragraph 2.7)
2.2 - Technical data:
 Structure in flanged plate with handle.
 Micro-processor operated temperature regulator.
 Safety thermostat with thermocouple.
 Switch test.
 Internal oven in stainless steel.
 Electronic control components thermally insulated.
 Forced air cooling system.
 Removable upper protection grid.
 Total absence of environmentally harmful cooling liquids.
 Socket with main cable and protection fuses.
 Display back light control.
 Electromagnetic compatibility : Emission EN50081-2
Immunity EN50082-2
 Model with copper block measuring 50mm diameter and insert of diameter 35mm
PTB60035CU-xx-x
 Operative range : Environment ÷ +600°C**
 Stability : ±0.05°C a 450°C **
 Reading accuracy : ±0,3°C a 450°C
 Maximum ascent rate : 20÷22°C/1’ **
 Maximum descent rate : 6÷10°C/1’ ** (t = 300°C).
 Standard insert : 5 holes ø3,2-4,5-6,5-9,5-11,5 x 185mm
 Weight of calibrator : 10Kg
 Display resolution : 0,01/0,1°C
 Reading accuracy : ±0,3°C a 450°C
 Regulation & reading probe : Pt 100 class A din43760
 Auxiliary input : Pt100 and Tc J, K, N, R, S, E(only for Model 2I)
 Reading : °C or °F or K.
 Interface : RS 232
 Temperature ramps : minimum 0,1°C/1’
 Thermostat test : 12 Vcc.
 Power supply : 230V 50/60Hz (110/115V by request)
 Power : 800VA.
 Size : 140x370 x 330 mm
 Case size : 330x520 x H. 500 mm
 Customized insert with drilled holes for best accuracy
NOTE: The data marked with ** has been recorded at an ambient temperature of 20°C±3, power supply
230V±10%, with Pt100 ø4.5mm inserted in the block.
The above-mentioned data keep valid for one year after the issuing of the calibrating certificate;
afterwards it is necessary to carry out the oven re-calibration.
Environmental range: temperature +10 ÷ +45°C, R.H. max. 80%.
MICROPROCESSOR DATA
* Display : 2 lines 20ch x line (3.2x5.5) back lighting.
* Resolution : 0.01°C/0.1°C.
* processor : 80C552
* A/D converter : Σ-∆ 24 bits
* E2PROM memory for recording parameters.
* RS232 Single serial output.
