Panel Panel Size and Type 48 cm (19") TFT color LCD panel
Viewing Angles (H, V) 178°, 178° (at contrast ratio of 10:1)
Brightness / Contrast 250 cd/m
2
/ 1000:1 (2500:1 Dynamic Contrast)
On/Off Response Time 20 ms (typical)
Midtone Response Time 8 ms (typical)
1
Native Resolution 1280 × 1024
Active Display Size (H × V) 376.3 × 301 mm
Viewable Image Size Diagonal: 481 mm
Pixel Pitch 0.294 × 0.294 mm
Display Colors 16.77 million from a palette of 1.06 billion
Cabinet Colors Gray, Black
Dot Clock Analog: 135 MHz, Digital: 108 MHz
Scanning Frequency (H, V) Analog 24.8 – 80 kHz, 50 – 75 Hz
Digital 31 – 64 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz)
Input Signals Analog: RGB Analog, Digital: DVI Standard 1.0
Input Terminals D-Sub mini 15 pin, DVI-D 24 pin (HDCP supported
2
)
USB Port / Standard 1 upstream port / USB Standard Rev. 2.0
Plug & Play VESA DDC 2B
Power Power Requirements AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz
Power Consumption 45 W (maximum), 24 W (typical)
Power Save Mode Less than 0.8 W
Physical
Specifica
-
tions
Height Adjustment Range With Height Adjustable Stand: 100 mm; With Arc-
Swing Stand: 104 mm; With EZ-UP Stand: 170 mm
Tilt / Swivel / Pivot With Height Adjustable Stand: 30° Up, 0° Down / 35°
Right, 35° Left / 90°; With ArcSwing Stand: 60° Up, 5°
Down / 172° Right, 172° Left / – ; With EZ-UP Stand:
25° Up, 0° Down / 172° Right, 172° Left / -10° – 92°
Dimensions (W × H × D) With Height Adjustable Stand: 405 × 406.5 – 506.5
× 205 mm; With ArcSwing Stand: 405 × 288 – 423.5
× 200 mm; With EZ-UP Stand: 405 × 347.7 – 507 ×
246.8 – 277.6 mm; With QM1: 405 × 334 × 77.5 mm
Net Weight With Height Adjustable Stand: 7.2 kg; With ArcSwing
Stand: 7.0 kg; With EZ-UP Stand: 8.8 kg; With QM1:
5.9 kg
Auto Brightness Functions Auto Brightness Stabilization, BrightRegulator
Auto Power Save Function Analog: VESA DPMS, Digital: DVI DMPM
Display Mode Options Fine Contrast (Text, Picture, Movie, CAD, sRGB,
Custom, WindowMovie
2
), Auto Fine Contrast
3
Screen-
Manager
OSD
Adjustment
Functions
Screen Adjustment Clock, Phase, Position, Range Adjustment (Auto),
Sharpness
Color Adjustment Brightness, Contrast, Temperature (in 500 K incre-
ments from 4,000 K – 10,000 K including 9,300 K),
Gain, Reset, Saturation, Hue, Gamma, ContrastEn-
hancer
Audio Volume (adjustable with front panel volume buttons)
Other Settings Signal Settings, Signal Switching, Product Informa
-
tion (product name, serial number, operating time),
BrightRegulator, Power Indicator, Adjustment
Lock, Languages (English, German, French, Italian,
Japanese, Simplified Chinese, Spanish, Swedish,
Traditional Chinese), Off Timer, Reset
Audio Dual 0.5 W built-in speakers, input / headphone jacks
Certifications and Standards TCO’03, TÜV/Ergonomics (including ISO 13406-2),
TÜV/GS, C-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus),
FCC-B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA EN
-
ERGY STAR
®
, RoHS, WEEE, EIZO Eco Products 2006
Supplied Accessories AC power cord, signal cables (D-Sub – D-Sub, DVI-D
– DVI-D), USB cable, audio cable, setup manual,
CD-ROM (PDF user’s manual, ScreenManager Pro
for LCD
4
, ICC profiles), 4 screws for mount option
warranty card, cable holder (EzUp stand option
only)
Warranty Five Years
5
1
Average response time measured between each grayscale level of 31, 63, 95, 127, 159, 191, and 223.
2
Window-
Movie mode is selectable only when Auto Fine Contrast is active.
3
Bundled ScreenManager Pro for LCD is necessary
to activate Auto Fine Contrast.
4
ScreenManager Pro for LCD is compatible with the Microsoft
®
Windows
®
98SE/
Me/2000/XP operating systems only.
5
The usage time is limited to 30,000 hours or less, and the warranty period of
the LCD panel and backlight is limited to three years from the date of purchase.
1 9 " C o l o r L C D M o n i t o r
Specifications
153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan
Phone +81-76-277-6792 Fax: +81-76-277-6793
www.eizo.com
All product names and logos are trademarks or registered trademarks of their respective companies.
ScreenManager, SlimEdge, FlexScan, and EIZO are registered trademarks of Eizo Nanao Corporation.
Specifications are subject to change without notice.
© 2007 Eizo Nanao Corporation.
Built-In Speakers
Dual 0.5 watt speakers are hidden
away at the bottom of the bezel so
as not to increase bezel size. If more
volume is needed, the optional i-Sound
L3 speaker unit (0.9 watts) is also available.
New OSD Menu
The FlexScan S1932 intro-
duces a new, intuitive OSD
menu. The OSD categories
are divided into layers and
icons are positioned directly above buttons for easy
identification.
Fine Contrast Mode Selection
The Fine Contrast feature offers five specialized image
adjustment modes: Text mode for word processing and
spreadsheet applications; Picture mode for graphics
applications; sRGB mode for web browsers or color
matching with devices that have an equivalent mode;
Movie mode for media player software; and for the
first time a CAD mode with virtually eliminates image
retention common with 3D CAD applications.
Digital and Analog Input Terminals
DVI-D and D-Sub mini 15-pin input terminals allow
the monitors to accept both digital and analog inputs.
If both types are connected, you can switch between
them via a front panel button.
10-Bit Gamma Correction
Ensures smooth, accurate color tones by converting the
8-bit PC data to 10-bit, assigning the ideal gamma val
-
ues then returning the data to 8-bit format for display.
Brightness Stabilization Function
A drift correction sensor quickly stabilizes the bright-
ness level after startup or coming out of power saving
mode. It also detects and automatically compensates
for brightness changes caused by surrounding tem-
peratures and the passage of time.
Customer Assurance
A five-year warranty offers a long service life, and
compliance with leading industry standards such as
TCO’03 and TUV Ergonomics ensures a better work
-
ing environment. The EIZO Eco Products 2006 label
indicates these products meet strict internal require
-
ments for design, manufacturing, packaging, and usage.
