Eizo FLEXSCAN S2232W User Manual

38
Chapter 5 Reference
Analog Input Signal (Sync) Separate, TTL, positive/ negative
Composite, TTL, positive/ negative
Analog Input Signal (Video) Analog, Positive (0.7Vp-p/75Ω)
Digital Signal Transmission System TMDS (Single Link)
Video Signal Memory Analog signal: 45 (preset: 16)
Digital signal: 10
Audio Output Speaker output: 0.5W + 0.5W (8Ω, THD: 3% or less)
Headphone output: 2mW + 2mW
Line input Input impedance : 48 kΩ (typ.)
Input level :1.0 Vrms (Max.)
Plug & Play VESA DDC 2B / EDID structure 1.3
Dimensions
(Width) ×
(Height) ×
(Depth)
Main unit (including
Height adjustable stand)
511 mm (20.1 inch) × 439 - 521 mm (17.3 - 20.5 inch) × 208.5 mm
(8.2 inch)
Main unit (including
Tilt stand)
511 mm (20.1 inch) × 415 mm (16.3 inch) × 205 mm (8.1 inch)
Main unit (including EZ-
UP stand)
511 mm (20.1 inch) × 351.5 - 516.5 mm (13.8 - 20.3 inch) × 279.9 mm -
307.5 mm (11.0 - 12.1 inch)
Main unit (without stand) 511 mm (20.1 inch) × 333 mm (13.1 inch) × 85 mm (3.35 inch)
Mass Main unit (including
Height adjustable stand)
Approx. 9.6 kg (21.2 lbs.)
Main unit (including
Tilt stand)
Approx. 7.6 kg (16.8 lbs.)
Main unit (including EZ-
UP stand)
Approx. 11.4 kg (25.1 Ibs.)
Main unit (without stand) Approx. 6.6 kg (14.6 lbs.)
Movable range Height adjustable stand Tilt: 40° Up, 0° Down
Swivel: 35° Right, 35° Left
Adjustable height: 82 mm (3.2 inch)
Rotation: 90° (clockwise)
Tilt stand Tilt: 30° Up, -5° Down
EZ-UP stand Tilt: 25° Up, 0° Down
Swivel: 172° Right, 172° Left
Adjustable height: 165 mm (6.5 inch)
Rotation: 90° (clockwise)
Environmental
Conditions
Temperature Operating temperature: 5 °C - 35 °C (41 °F - 95 °F)
Storage temperature: -20 °C - 60 °C (-4 °F - 140 °F)
Humidity Operating humidity: 30% - 80% R.H. (no condensation)
Storage humidity: 30% - 80% R.H. (no condensation)
Pressure Operating: 700 to 1,060 hPa
Storage: 200 to 1,060 hPa
USB Standard USB Specication Revision 2.0
Port Upstream port × 1, Downstream port × 2
Supply current Downstream: Max. 500mA/1 port
S2432W
LCD Panel 24.1-inch (610 mm) TFT color LCD with anti-glare
Viewing angle: Horizontal 178°, Vertical 178° (CR:10 or more)
Dot Pitch 0.270 mm
Horizontal Scan Frequency Analog: 31-94 kHz
Digital: 31-76 kHz
