Setting Up
User Manual Biosen C_line Clinic / GP+
14
14
5.2.3 Chipsensor
The chip sensors are the core of the measuring system. They convert
the sample concentration into an analysable, electrical signal. For further
information, see Section 15, page 52.
Only type II chip sensors from EKF-diagnostic GmbH may be used.
EKF-diagnostic GmbH offers chips sensors for glucose and lactate
determination as well as dummy sensors (see Section 16, page 54).
The device has at least one or optionally two measuring channels. With
two measuring channels, glucose and lactate can be measured from
one sample at the same time. The device recognizes the chip sensors
(glucose, lactate, dummy sensors) automatically. No manual settings
are required
It does not matter which sensor is placed in which measuring channel.
The same parameter can be measured on both channels. It is
recommended to equip measuring channel 1 with glucose and
measuring channel 2 with lactate. If a device with two measuring
channels is operated with only one sensor, there needs to be a dummy
sensor (accessory) in measuring channel 2. In this case it is
recommended to place the active sensor in measuring channel 1 (higher
measuring speed).
5.2.3.1 Sensor insert
Connect the device to the mains supply. The display will read "No
sensor found".
Open the sensor latch by pressing
it down on the open side.
Figure 5 - Opening the sensor latch
