Sampling
User Manual Biosen C_line Clinic / GP+
23
* The name is optional. If the name does not appear then the borderline
and the upper empty area of 4mm can be omitted, hence the barcode
can be extended.
6.3.3 Positioning of the barcode label
Figure 19 - Positioning barcode label
The label must be stuck centered to the hinge axis, vertically and without
folds. The label must not come off, particularly in the upper area, hence
press it on firmly.
Hinge of lid
Label must be
flush with rim of
micro test tube
Label must not
exceed bottom of
micro test tube
Name:
Name:
