Measurement operation
User Manual Biosen C_line Clinic / GP+
28
28
7.3 Result screen
The following figure shows the display window while measuring.
Figure 22 - Messung
Sample position (tray number – tray position – sample type):
The current tray number is raised by 1 every time measurement starts.
This can be pre-allocated in the menu, and is automatically set to 1 with
every cold start or change of date (at midnight).
The tray position displays the position of the sample on the sample tray
for this measurement.
The annex "H" or "S" indicates the sample type selected in the menu
(H – Hemolysate / S – Serum).
Measurements in control positions are indicated by "C1" or "C2",
measurements of urgent samples by "STAT".
Running sample number:
Running numbering of the measurement samples, the urgent samples
and the control samples.
Each sample type has its own circle of numbers which can be pre-
allocated. These circles of numbers are automatically set to 1 with every
cold start or change of date (at midnight).
The asterisk indicates, that this measurement is a double determination
of the current sample, selectable under menu item Warning limits (9.4,
page 35).
Measurement
Position 3-15 H
No. 5*
Running
sample number
Sample position
Memory
Info menu
stops
measurement
G 14,24
L 1,05
STAT
advised
BC: 1234567890
Barcode
mmol/L +
mmol/L -
Measuring
channel 1
Measuring
channel 2
