EKO INSTRUMENTS CO., LTD. - Pyranometer MS-80 - Instruction Manual Ver. 3
Pg. 45
Table A-8. Data Contents
Address
Data Type
Descriptions
Notes
0
UINT16
※
1
Serial Number 1º /2º ASCII Code
1
UINT16
Serial Number 3º/4º ASCII Code
2
UINT16
Serial Number 5º/6º ASCII Code
3
UINT16
Serial Number 7º/8º ASCII Code
4
UINT16
Serial Number 9º/10º ASCII Code
5
UINT16
Serial Number 11º/12º ASCII Code
6
UINT16
Serial Number 13º/14º ASCII Code
7
UINT16
Serial Number 15º/16 ASCII Code
8
UINT16
Measuring Instrument Model1º/2º ASCII Code
9
UINT16
Measuring Instrument Model3º/4º ASCII Code
10
UINT16
Measuring Instrument Model5º/6º ASCII Code
11
UINT16
Measuring Instrument Model7º/8º ASCII Code
12
UINT16
Measuring Instrument Model9º/10º ASCII Code
13
UINT16
Irradiance Minimum Output
14
UINT16
Irradiance Maximum Output
15
UINT16
Measurement Mode
A
16,17
FLOAT
※
2
Pyranometer Sensitivity
B
18
UINT16
Unit for Temperature
C
19,20
FLOAT
Measuring Voltage
D
21,22
FLOAT
Irradiance
E
23,24
FLOAT
Internal Temperature
F
25
UINT16
Password
G
26,27
FLOAT
Temperature Response Correction Factor1 – a
H
28,29
FLOAT
Temperature Response Correction Factor2 – b
30,31
FLOAT
Temperature Response Correction Factor3 – c
32,33
FLOAT
Temperature Response Correction Factor4 – d
34,35
FLOAT
Linearity Correction Factor 1 - k1
I
36,37
FLOAT
Linearity Correction Factor 2 - k2
38,39
FLOAT
Linearity Correction Factor 3 - k3
40,41
FLOAT
Linearity Correction Factor 4 - k4
※1: UINT16: Integer without 16 bits symbol.
※2: FLOAT: Single precision floating point number, Send and receive the low order word first then high
order word second
