EKO INSTRUMENTS CO., LTD. - Pyranometer MS-80 - Instruction Manual Ver. 3
EKO’s new generation sensor, called MS-80 broke with the rules of traditional pyranometer architecture.
The innovative design was inspired by the combination of latest technologies and state-of-the-art
thermopile sensor, enabling a breakthrough in unprecedented low zero-offset behaviour and fast
sensor response.
The compact sensor with single dome is immune to offsets and integrates all value added functions
such as a ventilator, heater and different industrial interfaces.
MS-80 unique properties:
Long term stability Compared to our conventional pyranometer, the long term stability is further
enhanced with improved airtightness and the sensor architecture with low sensitivity degradation.
Fast detector response The MS-80 is based on the latest thermopile technology, and realized with a
response time of <0.5sec @95% or <1sec @99%. Such response time is suitable for measuring solar
irradiance which changes momentarily.
Excellent temperature coefficient MS-80 has excellent temperature response in wide temperature
range compared to our conventional pyranometer, and it provides linear output against solar irradiance.
Lowest zero off-set Compared to the conventional pyranometers using double-dome, MS-80 has the
lowest zero off-set effects. The combination of the isolated thermopile detector architecture and optics
keep the sensor in thermal balance within variable atmospheric conditions.
Warranty and re-calibration The MS-80 has 5 years warranty and 5 years recommended re-calibration period.
ISO 9060, an international industry standard, was revised to the 2nd edition in 2018. Along with this revision, the
Pyranometers are classified in order of the highest grade "Class A" "Class B" "Class C" and for Pyranometers that
meet the response time and spectral selectivity criteria, "fast response pyranometer" and "spectrally flat
radiometer" are classified as a sub-category.
