EK-QUANTUM SURFACE RADIATORS
EK-Quantum Surface Radiators have a classical U-shape coolant
flow, with inlet and outlet both on one side of the radiator. However,
you can still choose which port of the radiator will serve as an inlet,
and which for the outlet in your custom loop.
SETUP 1
Picture on the left shows the first flow direction setup of the EK-
Quantum Surface P360M Radiator which is a Multiport radiator. On
the non-multiport radiator you can choose only one inlet and one
outlet port.
SETUP 1
OUTLET
OPTIONS
INLET OPTIONS
EK-Quantum Surface P360M
SETUP 2
Picture on the left shows the second flow direction setup of the EK-
Quantum Surface P360M Radiator which is a Multiport Radiator. On
the non-multiport radiator you can choose only one inlet and one
outlet port.
SETUP 2
INLET
OPTIONS
OUTLET OPTIONS
EK-Quantum Surface P360M
