ekwb EK-Quantum Surface P360M - Exploded View of Removable Components for S, P and X Series; EK-Quantum Surface S Series Components

- 6 -
EXPLODED VIEW OF THE REMOVABLE COMPONENTS FOR S, P AND X SERIES
For reference on picture above: EK-Quantum Surface S240
EKQUANTUM SURFACE S SERIES
2x QUANTUM
SURFACE
EXTENDER
2x QUANTUM SURFACE END TANK SHROUD
(ALUMINIUM)
2x QUANTUM SURFACE
SIDE PLATE
(STAINLES STEEL)
8x TORX SCREW M3 x 6 mm
QUANTUM SURFACE TANK
