g! CONFIGURATION DETAILS
The following table provides settings used in the g! Configurator. Please refer to the Configurator Reference Guide for more details.
o “<Select>” Select the appropriate item from the list (or drop-down) in the Configurator.
o “<User Defined>”, etc. Type in the desired name for the item.
o “<Auto>” This field will automatically populate during configuration
Devices Variable Name Setting Comments
Communication Devices Name
<User Defined> (Example: ELAN HR2)
Typ Ethernet
Communication Type ELAN HR2 Controlle
r
Location <User Defined> (Not Required)
Enable Sharing
Not Applicable
Sharing Port Not Applicable
Ethernet Address <Auto>
Port
<Auto> Default is 2000
Interface Devices<Auto Discover> Name
<User Defined> (Default: HR2 XXX.XXX.XXX.XX
X
)
See Note#1
Device Type ELAN HR2
COM Device
<Auto> (Example: ELAN HR2)
See Note #2
Power Button <Select> See Note #3
Auto – Return to Media <Select> See Note #4
On-Cradle Zone <Select> See Note #5
Timeout <Select> See Note #6
Notes:
1. The HR2 remotes are automatically discovered; refer to Initial Configuration Notes above
2. If not already chosen, select the COM device that refers to the HR2 Comm. Device set above
3. Select the desired Power button behavio
r
4. Select the desired return to media control time
5. Select the desired zone to switch to when cradled
6. Select the desired sleep timeout behavio
r
Only 1 Com device required for HR2(s)
