Elan S1616A Installation Manual

ELAN HOME SYSTEMS S1616A INSTALLATION MANUAL
© ELAN Home Systems 2012 | All rights reserved.
Page 1
Preface
Purpose of this Manual
This manual provides design information, step-by-step installation instructions and connection examples, along with basic user information
for installation and ongoing use of the S1616A Multi-Zone Controller Amplifier. This manual is written for the installer of this equipment.
This manual only covers the S1616A when used in Multi-Zone Mode. For installation instructions for using the S1616A in Amplifier Mode
please download the S1616A Amplifier Mode Installation manual at www.elanhomesystems.com/dealer.
Organization
The following information is contained in this manual:
Safety Information
Provides a comprehensive list of safety practices and procedures allowing for the safe installation and
operation of the ELAN Home Systems S1616A Multi-Zone Controller Amplifier.
S1616A Introduction
Provides an introduction to ELAN Home Systems S1616A Multi-Zone Controller Amplifier, along with system
features to include Front and Rear panel controls, indicators and connections, along with a short description of
each.
S1616A Design
Provides information that will allow you to positively implement the S1616A’s features in your installations.
S1616A Connections
Provides a description of the S1616A Multi-Zone Controller Amplifier system connections and direct
connections from the S1616A to other components.
Troubleshooting
Provides troubleshooting tables to help fix common problems that may be encountered when installing the
S1616A Multi-Zone Controller Amplifier.
Specifications
Provides equipment specifications for the S1616A Multi-Zone Controller Amplifier.
Appendix A
Programming with Configurator.

Elan S1616A Specifications

General

Brand	Elan
Model	S1616A
Category	Amplifier
Language	English
