Elation 5R - Page 46

Platinum Spot 5R™
©Elation Professional, Los Angeles Ca. 46 www.ElationLighting.com
200-207
Macro 10
208-215
Macro 11
216-223
Macro 12
224-231
Macro 13
232-239
Macro 14
240-247
Macro 15
248-255
Macro 16
Rotating prism, Prism / Gobo macros:
0-127
Prism indexing
128-189
Forwards prism rotation from fast to slow
190-193
No rotation
10
8
13
194-255
Backwards prism rotation from slow to fast
Rotating Prism indexing Fine
14
0-255
Fine indexing
Focus:
11
9
15
0-255
Continuous adjustment from near to far
Focus Fine:
16
0-255
Continuous adjustment Fine
Shutter, strobe:
0-31
Shutter closed
32-63
No function (shutter open)
64-95
Strobe effect slow to fast
96-127
No function (shutter open)
128-159
Pulse-effect in sequences
160-191
No function (shutter open)
192-223
Random strobe effect slow to fast
12
10
17
224-255
No function (shutter open)
Dimmer intensity:
13
11
18
0-255
Intensity 0 to 100%
Fine Dimmer intensity:
19
0-255
Dimmer intensity fine
Iris:
0-191
Maximum diameter to minimum diameter
192-223
Pulse closing fast to slow
14
12
20
224-255
Pulse opening slow to fast
Iris Fine:
21
0-255
Iris Fine
Frost:
0-191
Frost 0~100%
15
13
22
192-223
Pulse opening fast to slow
