Platinum Spot 5R™
©Elation Professional, Los Angeles Ca. 58 www.ElationLighting.com
21. TECHNICAL SPECIFICATIONS
Power supply
Power Requirements
120v/60Hz
Fuse Protection
120V = 5A/250V, GMA (5x20mm fine-wire fuse)
220V = 3.15A/250V, GMA (5x20mm fine-wire fuse)
Power Consumption
350 Watts
Lamp
Type
MSD Platinum 5R (Phillips)
Lamp Wattage
150-189
Life time
2000 Hrs
Color temperature
8000˚ K
Luminous flux
7950Lm
CRI
75
Optical system
Parabolic dichroic glass reflector
Beam angle 16˚
Lenses hardened and tempered, anti-reflex coated
Colors
8 dichroic filter plus white, half-color compatible
Gobos
Gobo-wheel 1: 8 interchangeable rotating gobos plus "open", 4 glass Gobos
Gobo-wheel 2: 14 fixed gobos plus "open"
Gobo outside diameter 14 mm, image size 7 mm
Gobo thickness (max): glass = 1 mm, steel = 0.15 mm
Prism
Rotating 3-face prism, rotating and variable in speed
Shutter / Strobe / Dimmer
Strobe effect with variable speed 1 - 10 flashes per second
Continuously mechanical dimmer 0 - 100%
Iris
Motor driven iris from open to close, variable speed, pulse effect
Focus
Motor driven focus from near to far away
DMX Channels
17 (16bit – default) or 15 (8bit – user selectable) or 24 (16bit – user selectable)
Drive
Standard DMX-512, 3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1 or 5 pole XLR; n/a = Pin
5, n/a = Pin 4, [+] = Pin 3, [-] = Pin 2, [Ground] = Pin 1
Starting DMX [001].
Pan / Tilt
Pan - movement
630° in max. 2.0 seconds, 16 bit resolution
