• Reversible DMX Polarity Output
• 64 DMX Channels
• 8 Scanners buttons (up to 8 Channels each)
• 4 Programs of 99 steps
• 96 Scenes in 24 Pages
• Assignable Joystick
• Audio Program
• Speed and Fade time adjustments
• Blackout Delay Adjustment
• Backup Memory using a 32 MB Compact Flash Card (Not Included and
Optional)
DMX Programmer™ Features
DMX Programmer™ Program Flow Chart
Elation Professional® www.elationlighting.com - DMX Programmer Page 2
RECORD SCENES
FLOW CHART
This is the order you program the DMX Programmer.
ADDRESS
FIXTURES
RECORD PROGRAMS
PLAYBACK PROGRAMS
