ELAUT Benchmark Games Fireball - RGB LED Controller Board Pinouts

21
J4
6
INPUTS
Internal row, Wheel Score Sensor
J4
7
INPUTS
Player Sw.2/Menu Down sw.
J4
8
INPUTS
Menu / Enter switch
J1
1
GROUND
12V Negative
J1
2
GROUND
12V Negative
J1
3
12V+
12V Positive
J1
4
12V+
12V Positive
J2
1
Speaker -
Speaker Negative
J2
2
GROUND
Ground
J2
3
Speaker +
Speaker Positive
485
1
RS485 A
Serial COM Port
485
2
RS485 B
Serial COM Port
RGB LED Light Controller Board:
Connector
Pin #
Type
Definition
J5
1
12V
12V Positive
J5
2
GND
12V Negative
J5
3
SYNC
J5
4
RS485 A
Serial COM Port
J5
5
12V
12V Positive
J5
6
GND
12V Negative
J5
7
N/C
J5
8
RS485 B
Serial COM Port
J1
1
DATA
Left Side (Length 18)
J1
2
GND
Left Side
J1
3
12V
Left Side
J2
1
DATA
Right Side (Length 18)
J2
2
GND
Right Side
J2
3
12V
Right Side
J3
1
DATA
Ball Drop (Length 7)
J3
2
GND
Ball Drop
J3
3
12V
Ball Drop
J4
1
DATA
Console (Length 4)
J4
2
GND
Console
J4
3
12V
Console
