Elba EL 810 - REPLACING THE OVEN LAMP;S (HALOGEN)

32
REPLACING THE OVEN LAMP/S (MODELS WITH HALOGEN LAMP/S)
WARNING: Ensure the appliance is switched off before replacing the lamp to avoid
the possibility of electric shock.
• Let the oven cavity and the heating elements to cool down.
• Switch off the electrical supply.
TOP RIGHT LAMP:
• Remove the protective cover “C” (g. 2.10b).
• Replace the halogen lamp “B” with a new one suitable for high temperatures (300°C)
having the following specications: 220-240V, 50/60Hz and same power (check watt
power as stamped in the lamp itself ) of the replaced lamp.
 IMPORTANT WARNING: Never replace the bulb with bare hands; contamination from
your ngers can cause premature failure. Always use a clean cloth or gloves.
• Ret the protective cover.
LEFT LAMP (SOME MODELS ONLY):
• Remove the left wire rack (and the side catalytic panel for the models with side catalytic
panels) by unscrewing the xing screws.
• Press down from the top the protective cover “A” (g. 2.10b) and remove it by rotating
on the lower side. IMPORTANT: never use screwdrivers or other utensils to remove
the cover “A”. This could damage the enamel of the oven or the lampholder.
 Operate only by hands.
• Replace the halogen lamp “B” with a new one suitable for high temperatures (300°C)
having the following specications: 220-240V, 50/60Hz and same power (check watt
power as stamped in the lamp itself ) of the replaced lamp.
 IMPORTANT WARNING: Never replace the bulb with bare
hands; contamination from your ngers can cause premature
failure. Always use a clean cloth or gloves.
• Ret the protective cover “A” operating in reverse order.
ATTENTION: the notch in the inner edge of the cover must
be oriented toward the lamp.
• Assemble the left wire rack (and the side catalytic panel with
the arrow up for the models with side catalytic panels).
Note: Oven bulb replacement is not covered by your
guarantee.
Fig. 2.10b
A
B
B
C
1
2
A
A
WRONG
CORRECT
