Elba EL 810 - Page 40

40
3. Replace the inner pane:
• Check that the four rubber pads are in
place (“D” in g. 2.38).
 IMPORTANT: It is advisable, while
retting the glass, to keep pressed in
position the four rubber pads “D”, by a
nger, to avoid breakage or slippage of
the rubber pads themselves (g. 2.39).
• Check that you are holding the pane
the correct way. You should be able to
read the wording on it as it faces you.
• Insert the pane in the left “E” and right
“F” slide guides (g. 2.39), and gently
slide it to the retainers “H” (g. 2.40).
• Reassemble the seal “G” in the correct
way (g. 2.41) by hooking the no. 3
xing hooks in the proper holes (g.
2.42).
4. Unlock the oven door by opening it
completely and closing the lever “A”
on the left and right hinges (fig. 2.43).
D
G
Fig. 2.42
Fig. 2.38
Fig. 2.41
H
Fig. 2.40
A
Fig. 2.43
It is normal the opened gap between
the top edge of the inner glass and the
sealed gasket. This allows the cooling air
circulation.
The oven door
has a sealed
gasket in the top
part.
F
E
Fig. 2.39
