35
CLEANING THE DOOR GLASS – TOP-OPENING MODELS
cont....
4 Insert the pane into the slide guides
and slide it to the bottom retainers.
Slide guides
5 Replace the seal (some doors only).
6 Open the door fully and close the
levers.
Seal
Lever
4 Insert the pane into top clamps then
lower and slide into bottom clamps.
1
2
1
3
5 Check the rubber pads are in place.
Rubber pads
1
Bottom
retainers
6 Check the pane is the right way
around . You should be able to read
any wording that may be on the pane.
MODELS WITH INNER PANE ONLY MODELS WITH INNER AND MIDDLE PANES
