13
Information level
TWW
temperature of the first storage tank for
hot water destratification: Sensor input
S7 is automatically assigned when the
relevant schematic is selected (KON,
E3 -1 / 1).
TSPO
Temperature measurement in the up-
per part of the storage tank for which
hot water destratification was activated.
TH1
temperature measurement for first ther-
mostat function: Use parameter STH1
to assign a sensor input (parameter 56,
Level E3 – 7/ 1).
TH2
temperature measurement for second
thermostat function: Use parameter
STH2 to assign a sensor input
(parameter 60, E3 – 7 / 5).
