HOW TO USE YOUR MOTORHOME’S EQUIPMENT
HOW TO MAKE UP YOUR BEDS
130
Step 1 Remove all cushions from the front and rear facing seats.
Step 2 Pull out the bed slats located between 1 and 2 and fully extend as shown.
Step 3 Place cushions as shown in the diagram.
130
1 - REAR FACING BASE CUSHION
2 - FORWARD FACING BASE CUSHION
3 - REAR FACING BACKREST CUSHION
4 - NEARSIDE BACKREST CUSHION
5 - MAKE UP CUSHION 955 x 290
6 - MAKE UP CUSHION
7 - FORWARD FACING BACKREST CUSHION
46
3
1
2
7
N/SIDE
O/SIDE
N/SIDE
NIGHT LAYOUT FRONT
DAY LAYOUT FRONT
4
1
3
5
2
