ESIM120 Manual v.3.6
closing, depending on the current gate state and selected output type NO or NC. If there is more than one listed caller dialing to the system
at the same time, the system will accept the incoming call from the caller who was the rst to dial while other caller (-s) will be ignored.
The system supports a conrmation phone call to user/administrator phone number. For more details, please refer to 11.4. Output Con-
trol Conrmation by Call Back
Set output pulse
duration
SMS
SMS text message content:
ssss_TIMERo:pl
Value: ssss – 4-digit SMS password; o – output number, range [1 – output C1; 2 – output C2];
pl – pulse duration, range – [1... 10] seconds.
Example: 1111_TIMER2:4
Cong
Tool
This operation may be carried out from the PC using the ELDES Conguration Tool software.
NOTE: ELDES Conguration Tool software allows to set the unlimited output pulse duration value.
11.3. Output Control by SMS Text Message
To open or close the gate, send the SMS text message from any of 5 available administrator phone numbers (see 8. USER PHONE NUM-
BER DATABASE for phone number management). The system will turn ON the output (-s) for a determined time period (pulse) resulting
in the gate opening or closing, depending on the current gate state. The conrmation reply by SMS text message, containing the output
name (see 11.1. Output Names), will be sent to the administrator phone number that the output control by SMS text message was ini-
tiated from.
To instantly turn ON/OFF the output and set its state to ON/OFF when the system starts-up, please refer to the following conguration
methods.
Turn ON output for
time period
SMS
SMS text message content:
ssss_Co:ON:hr.mn.sc or ssss_out-name:ON:hr.mn.sc
Value: ssss – 4-digit SMS password; o – output number, range - [1... 2]; hr – hours, range –
[00... 23]; mn – minutes, range – [00... 59]; sc – seconds, range – [00... 59]; out-name – up
to 16 characters output name.
Example: 1111_C2:ON:00.00.09
Cong
Tool
This operation may be carried out from the PC using the ELDES Conguration Tool software.
Turn OFF output for
time period
SMS
SMS text message content:
ssss_Co:OFF:hr.mn.sc or ssss_out-name:OFF:hr.mn.sc
Value: ssss – 4-digit SMS password; o – output number, range - [1... 2]; hr – hours, range –
[00... 23]; mn – minutes, range – [00... 59]; sc – seconds, range – [00... 59]; out-name – up
to 16 characters output name.
Example: 1111_C1:OFF:00.11.49
Cong
Tool
This operation may be carried out from the PC using the ELDES Conguration Tool software.
To instantly turn ON/OFF the specied output and set its state to ON/OFF when the system starts-up, please refer to the following con-
guration methods.
Turn ON output/Set
output start-up state
as ON
SMS
SMS text message content:
ssss_Co:ON or ssss_out-name:ON
Value: ssss – 4-digit SMS password; o – output number, range - [1... 2]; out-name – up to 16
characters output name.
Example: 1111_C1:ON
Cong
Tool
This operation may be carried out from the PC using the ELDES Conguration Tool software.
