EWD3 WIRELESS MAGNETIC DOOR CONTACT/SHOCK SENSOR/FLOOD SENSOR-READY

6. BATTERY REPLACEMENT

1. Open EWD3 enclosure.

2. Remove the old batery from the batery slots.

3. Insert the new Primary 3V Lithium 1500mAh CR123A type batery based on the batery slot posiive/negaive terminals indicated on the PCB of EWD3.

4. Batery replaced.

• We strongly recommend to use quality brand bateries, such as: GP, Ansmann, Energizer.

• Only Primary 3V Lithium 1500mAh CR123A bateries can be used. Install only new, high quality and unexpired batery.

• The batery must be removed or plasic tab inserted between the batery slot and the batery if the device is not in use.

• In order to avoid ire or explosion hazards, the system must be used only with approved batery.

• Special care must be taken when connecing posiive and negaive batery terminals.

• Dispose old bateries only into special collecion sites.

• Do not charge, disassemble, heat or incinerate old bateries.

• The batery status can be monitored in real-ime using ELDES coniguraion sotware.

• The system sends an SMS text message to the listed user phone number as soon as the batery level runs below 5%.

7. RESTORING DEFAULT PARAMETERS

1. Press and hold the RESET buton.

2. Hold the RESET buton and watch the LED indicator quickly lash (for

approx. 5 seconds.).

3. Release the RESET buton.

4. Parameters restored to default.

8. TECHNICAL SPECIFICATIONS

Compaible with:

• ESIM364 v02.16.00 and up.

• ESIM384 all versions

• PITBULL ALARM v2.05.00 and up.

• PITBULL ALARM PRO all versions.

Batery 3V Lithium 1500mAh CR123A type; CR17345 (IEC) / 5018LC (ANSI/NEDA)

Number of bateries 1

Batery operaion ime Up to 5 years*

Wireless band ISM868 or ISM915**

Wireless communicaion range Up to 30m (~98t) in premises; up to 3000m (~9843t) in open areas

Range of operaing temperatures -20…+55 °C (-4... +131°F)

Humidity 0-90% RH @ 0... +40°C (0-90% RH @ +32... +104°F) (non-condensing)

EWD3 dimensions 117x22x22mm (4.61x0.87x0.87in)

Magnet dimensions 47x13x10mm (1.85x0.51x0.39in)

Compaible with alarm systems ELDES wireless

* The operaion ime may vary under diferent condiions. ** Depends on region.
