EWD3 WIRELESS MAGNETIC DOOR CONTACT/SHOCK SENSOR/FLOOD SENSOR-READY
EN
1 . GENERAL OPERATIONAL DESCRIPTION
EWD3 is a wireless device intended to secure doors, windows or any other opening/closing mechanisms. In addiion, the device comes equipped
with a built-in shock sensor for vibraion detecion (drilling, knocking, hammering etc.), an on-board zone terminal designed for external NO/NC
sensor, EOL (end-of-line) sensor (for double-leaf door or 2nd window security) or lood sensor (for water leak detecion) connecion and a tamper
switch for enclosure state supervision in case it is illegally opened or detached from the wall. In order to start using EWD3, it has to be paired with
ELDES alarm system using ELDES coniguraion sotware or by sending a corresponding SMS text message to ELDES alarm system.
PITBULL ALARM and PITBULL ALARM PRO alarm systems support up to 16 EWD3 devices, while ESIM364 - up to 32 EWD3 devices, and
ESIM384 - up to 64 EWD3 devices. The maximum wireless connecion range is 3000m (~9843t) (in open areas).
DESCRIPTION
DETECTOR Hall efect sensor
 /  Batery slots
RESET Buton for restoring default parameters
COM Common terminal
Z Zone terminal
LED Light-emiing diode for status indicaion
TAMPER Tamper switch
FRONT
DETECTOR
DETECTOR
LED
