ELDES WIRELESS TOUCHPAD EWKB5
1 . GENERAL OPERATIONAL DESCRIPTION
DEVICE FEATURES
• Arming and disarming
• Violated zone bypass and bypassed
zone acivaion
• PGM output control
• Customizable user-friendly graphical
menu
• Navigaion through the menu using the
touch screen
• Mulilingual voice-guided audio
instrucions
• Adjustable brightness and volume level
• Batery or externally-powered
EWKB5 has 1 built-in zone terminal, which is by default designed for passive wired
digital sensor connecion, such as magneic door contact, and 2 tamper switches for
enclosure state supervision in case it is illegally opened or detached from the wall.
Regardless if the tamper switch alone is to be used, the zone must be enabled and the
resistor of 5,6kΩ nominal must be connected across Z1 and COM connectors (illustrated
on page 4). It is possible to connect up to 2 EWKB5 devices to alarm systems. The
maximum wireless connecion range is 1000m (~3281t) (in open areas).
MAIN MENU FEATURES
• Pariion buton – arms/disarms the system once a valid master/user code is entered;
indicates pariion status (armed/disarmed),presence of system faults.
• Quick arm buton – arms the system by touching and holding this buton; master/
user code not required (customizable, hidden by default; not shown in picture).
• Fire – instantly causes ire alarm by pressing and holding this buton (customizable,
hidden by default).
• Panic – instantly causes silent alarm by pressing and holding this buton
(customizable, hidden by default).
• Controls – opens PGM output menu, thus leing you turn a certain PGM output ON or
OFF (customizable, hidden by default).
• Seings – grants access to seings menu once a valid master code is entered.
PITBULL PRO: 27
o
C
PITBULL
PRO
Panic Fire Controls Seings
01:19
!
DIGITAL
CLOCK
LOW
BATTERY
LOW WIRELESS
SIGNAL
TEMPERATURE
PARTITION
BUTTON
