ELECRAFT K2/100 - Page 6

6
Ref. Designator(s)
QTY
Description
Part #
C66
1
Cap., 180 pF ("181"), 5%, 50V disc, 0.2" LS; voltage may not be marked
E530008
C67,C80,C81,C86
4
Cap., .0047 µF ("472"), 10%, 100V disc, 0.25" LS
E530102
C2E,C83
2
Cap., 1000 pF ("1000"), 5%, 500V silver mica
E530085
C2A,C6D
2
Cap., 1200 pF ("6122"), 630V polypropylene
E530033
C2C
1
Cap., 2200 pF ("2200"), 5%, 500V silver mica
E530086
C84
1
Cap., .001 µF ("102"), 5%, 50V mono, 0.1" LS
E530074
C25,C69,C70,C87,
C88, CTRL-Ctxd
6
Cap., .001 µF ("102"), 5%, 50V mono, 0.2" LS
(CTRL-Ctxd may be needed for K2 Control board; see text)
E530001
C82
0
Not used
-
C71
1
Cap., .0018 µF ("182"), 5%, 200V mono, 0.2" LS
E530104
C64, C79
2
Cap., .0047 µF ("4n7J250"), 5%, 250Vor greater, mono, 0.4" LS
E530262
C7,C8,C9,C12–C22,
C24,C28,C29,C32,
C50,C65,C72,C73,
C74,C76,C97–C99
27
Cap., .01 µF ("103"), 5%, 50V mono, 0.1" LS
E530019
C37,C38,C39,C44,
C46,C68,C89,C90
8
Cap., .01 µF ("103"), 5%, 50V mono, 0.2" LS
E530009
C36,C42,C43,C77
4
Cap., .015 µF ("153" or "15N"), 5%, 250V mono, 0.2" LS
E530082
C31
1
Cap., .22 µF ("µ22J63"), 5%, 63V mono, 0.2" LS
E530295
C48,C49,C52,C53,
C54,C55,C56,C57,
C61,C62,C63,C85
RF-Crf
13
Cap., .047 µF ("473"), 5%, 50V mono, 0.2" LS
(RF-Crf may be needed for the K2 RF board; see text)
E530025
C30,C33,C34,C75
4
Cap., 0.1 µF ("104"), 20%, 50V mono, 0.1" LS
E530020
C10,C11,C23,C35,
C58,C59,C40,
CTRL-C42
8
Cap., 0.1 µF ("104"), 5%, 50V mono, 0.2" LS
(CTRL-C42 may be needed for the K2 Control board; see text)
E530011
C27
1
Cap., 10-50 pF ceramic trimmer, yellow color
E540002
C1
1
Cap 3-11 ceramic trimmer, white color:
NOTE: This trimmer is packaged in a separate envelope to help you avoid
confusing it with C27. Keep it in its envelope until you are instructed to
install it.
E540012
C60
1
Cap., 100 µF, 16V electrolytic
E530061
C51
1
Cap., 470 µF, 25V electrolytic
E530084
D1-D8
8
Diode, 1N4148
E560002
D9
1
Diode, SB530
E560003
D10,D13
2
Diode, 1N5404
E560010
D11,D12,D14
3
Diode, 1N4007
E560001
