ELECRAFT K2/100 - KPA100 Parts Inventory and Preparation

5
Parts Inventory
Set the heat sink, shield, and painted panels aside until needed. Leave them wrapped to protect their finish.
You should do a complete inventory (see below), which may take an hour or more. If anything is missing, contact Elecraft. Color codes and other
markings are shown in parentheses. Refer to Appendix A of the owner's manual for more parts photos.
Some components in this kit can be damaged by static discharge. Before handling diodes, transistors, and ICs, touch a grounded, unpainted metal
surface, or use a wrist strap.
Parts List Notes:
 LS = lead spacing in inches (metric conversions: 0.1" = 2.5 mm, 0.2" = 5 mm, 0.4" = 10 mm.)
 In some cases, two capacitor types will have the same value but different voltage ratings or lead spacing (LS). To avoid assembly errors, you
must positively identify these capacitors and keep them separate from each other. Use your DMM to verify values if possible.
 Parts whose reference designators are shown in bold are for use on the K2 RF or Control boards.
 Flat-head screws are measured from the top of the head; pan head screws are measured from beneath the head.
Ref. Designator(s)
QTY
Description
Part #
C5B
1
Cap., 18 pF ("18"), 5%, 500V or 1KV disc, 0.2" LS (may have black band)
E530088
C3B,C4B
2
Cap., 27 pF ("27"), 5%, 500V or 1KV disc, 0.2" LS
E530089
C5F
1
Cap., 33 pF ("33"), 5%, 500V or 1KV disc, 0.2" LS
E530090
C3H
1
Cap., 39 pF ("39"), 5%, 500V or 1KV disc, 0.2" LS
E530091
C5D
1
Cap., 47 pF ("47"), 5%, 500V or 1KV disc, 0.2" LS
E530092
C4D
1
Cap., 56 pF ("56"), 5%, 500V or 1KV disc, 0.2" LS (may have black band)
E530093
C5A,C6C
2
Cap., 68 pF ("68"), 5%, 500V or 1KV disc, 0.2" LS
E530094
C3E,C5G
2
Cap., 82 pF ("82"), 5%, 500V or 1KV disc, 0.2" LS
E530095
C4E
1
Cap., 120 pF ("121"), 5%, 500V or 1KV disc, 0.2" LS
E530096
C3G,C4A,C5C,C5E,
C6E
5
Cap., 150 pF ("151"), 5%, 500V or 1KV disc, 0.2" LS
E530097
C2B,C3C,C3J
3
Cap., 220 pF ("221"), 5%, 500V or 1KV disc, 0.2" LS
E530098
C3A,C3D,C4C,C6F
4
Cap., 270 pF ("271"), 5%, 500V or 1KV disc, 0.2" LS
E530099
C3F,C6A,C6B,C6G
4
Cap., 330 pF ("331"), 5%, 500V or 1KV disc, 0.2" LS
E530100
C2D
1
Cap., 390 pF ("391"), 5%, 500V or 1KV disc, 0.2" LS
E530101
C26
1
Cap., 33 pF ("33"), 5%, 50V disc, 0.2" LS (do not confuse with C5F)
E530064
C41,C95
2
Cap., 100 pF ("101"), 5%, 200V disc, 0.2" LS
E530034
