Receive Icons
Below each S-meter is a collection of icons pertaining to that receiver's
configuration. These indicate the current settings of the preamps
(PRE), attenuators (ATTN), noise blanker (NB), noise reduction (NR),
audio peaking filter (APF), manual or automatic filtering (NTCH),
automatic gain control (AGC), and receive antenna (e.g., ANT1 or
RXANT1).
For details see RECEIVER SETTINGS and ANTENNA SELECTION.
Panadapter
The panadapter shows both a spectral display and waterfall. Single
(VFO A or B) or dual panadapters can be shown. To adjust the
panadapter's reference level, span, averaging, or other parameters,
tap the <DISPLAY> primary function button, followed by the secondary
function button for the target parameter.
You may also need to specify whether the operation is targeting the
LCD or external display or both, and in dual-pan mode, whether the
target is VFO A, VFO B or both. These selections are made using the
two buttons groups that appear to the left of the parameter
adjustment control.
For details, refer to the PANADAPTER section.
Mini-Pan
The mini-pan shows a narrow range of spectrum for fine-tuning of
signals. (The data points are not simply magnified; they are resampled
to ensure high resolution.) To display the mini-pan, tap the S-meter for
either receiver.
In CW and PSK modes, AUTO-spot centers this signal by automatically
adjusting the VFO frequency.
