FM Operation
To setup for repeater use:
• Hold [ALT] switch to select simplex, TX up (FM+), or TX down (FM-).
You can also change this setting using <TX> <RPT mode>.
• Set up repeater offsets using <TX> <RPT OFS>.
• Set up VFO coarse-tuning step size using the VFO Coarse
Tuning menu entry.
• Set up PL tone encode pitch and on/off using <TX> <PL TONE>.
• To set up voice and PL tone deviation, use FM Deviation,
Voice and FM Deviation, Tone.
• DTMF tones (dual-tone, multi-frequency) can be transmitted in FM
mode. Use <TX> <DTMF> to bring up the DTMF window. Hold PTT, tap
digits or symbols on the provided keypad, then release PTT. You can
also create stored DTMF commands. Hold <CMD1> - <CMD6> to enter
a sequence. Tap the return arrow to complete entry. The CMD button
can then be tapped to play the sequence back (while PTT is asserted).
DATA MODES
The K4 has four data modes: DATA, AFSK, FSK, and PSK. These are
further described below.
There are also manual sections dedicated to setup requirements for
RTTY (RTTY CONFIGURATION) and FT8/JT/etc. (FT8 / JT / ETC.
CONFIGURATION).
Built-In Data Modes
The K4's built-in data modes include FSK (RTTY) and PSK (PSK31 or
PSK63). In these modes, you can turn on text decode to have
demodulated characters appear on the display. You can also transmit
in data modes using your keyer paddle or with a keyboard connected
to any of the USB type A jacks.
