• 2. Connect the soil moisture sensor to the GrowCube and insert the other end into the soil. There are
four sensor interfaces(Marked A to D) on the GrowCube, and you can connect a sensor to any one of
them. For example, when using port a to water plants, connect the sensor to port A of the GrowCube
(Pay attention to the buckle position of the sensor connector and device interface). Then insert the soil
moisture sensor vertically into the soil, the insertion depth should be more than 2/3 of the sensor, and
the sensor insertion position should be as close as possible to the rhizome of the plant.
A: The insertion position is too far from the B: The sensor is inserted too shallow
root of the plant
C: The sensor is inserted too deep
05
