Electra COMPACT 7 - Page 50

Model:
CON-12 ST R407C
No. Part No. Description Qty
1 4516158 PAINTED COVER PANEL ASSY. 1
2 4521257 OUTDOOR GRILLE PAINTING ASSY 1
3 436358 Left Handle 1
4 4516159 Front Panel 1
5 4516160 PAINTED BASE ASSY. 1
6 460129 PAINTED SIDE PANEL ASSY. 1
7 436357 Right Handle 1
8 204107 Big Cable Clip Nylon 1
9 253046 Clip set PVC 1
10 236332 6 Poles Terminal Block 1
11 4511168 Wire Clip 1
12 4518022 Cap. Clip 1
13 201130 Nut (For Capacitor) 1
14 203008 Washer (For Capacitor) 1
15 45500001 Capacitor for Fan Motor (2uF/450V) 1
16 45500504 Capacitor for Compressor (35uF/400V) 1
17 4523418 Compressor assy (PG215X2C-4FS) 1
18 4516357 Rubber Cushion 3
19 391498
W
ire assy
1
20 4516406 Gas Valve (1/2") 1
21 4516408 Liquid Valve (1/4") 1
22 4516522 Suction Tube 1
23 452785200 Discharge Tube 1
24
452786300
Capi. Assy 1
25 4516156 Back Panel 1
26 452763300 Condensor Assy. 1
27 4513965 Patition Plate 1
28 323156 Motor Support 1
29 261507 Fan Motor 1
30 293289 Fan 1
31 201130 Nut (For Fan) 1
COMPACT-12ST Spare Parts List (R407C
)
Rev.: A
Series: IOD/CON
Date: 12/01/2004
ELECTRA CONSUMER PRODUCTS LTD
