2-7
PRODUCT DATA SHEET
Revision Y05-01Service Manual - EMD Series
Model (Indoor & Outdoor)
EMD 40 & OU10-38 RC R22
Installation method Ducted
Characteristics Units Cooling Heating
Btu/Hr 37700 40200
Capacity
Kw 11.0 11.6
Power input Kw 3.9 3.5
COP W/W 2.82 3.32
Power supply V/Hz/Ph 230V/50Hz/1PH
Rated current A 17.9 15.9
Starting current A 114.0
Circuit breaker rating A 25
Fan type & quantity Centrifugal & 1
Fan speeds H/ M/ L RPM 1130 1020 830
Air flow * H/ M/ L M³/Hr 1740 1530 1250
External static pressure Min-Max Pa 37- 80
Sound power level ** H/ M/ L dBa 70.8 67.1 62.8
Sound pressure level *** H/ M/ L dBa 54.1 50.6 49.2
Moisture removal Lt/Hr 3.6
Condensate drain tube I.D mm 19
Dimensions W/ H / D mm 785 400 595
Weight Kg 36
Package dimensions W/ H / D mm 825 425 610
Package weight Kg 38
Units per pallet Units 8
INDOOR
Stacking height Units 4
Refrigerant control Capillary tube
Compressor type Scroll
Fan type & quantity Axial & 2
Fan speeds H / L RPM 1125
Air flow H / L M³/Hr 4150
Sound power level H / L dBa 65
Sound pressure level *** H / L dBa 58
Dimensions W/ H / D mm 900 970 350
Weight Kg 88.5
Package dimensions W/ H / D mm 985 1020 435
Package weight Kg 93
Units per pallet Units 6
Stacking height Units 2
Refrigerant type R22
Charge / Distance Kg/ M 2.65 / 7.5
Additional charge per 1 meter Grams 30
Liquid line Inch 3/8
Suction line Inch 3/4
Max. tubing length Meter 50
OUTDOOR
Connections
between
units
Max. height difference Meter 25
Operation control type LCD Remote control
Heating elements Kw No
Others Crankcase heater (60W)
* Airflow in ducted units; according to nominal external static pressure.
** Sound power in ducted units is measured at air outlet side.
*** Sound pressure level is measured at 1-meter distance from the unit.
