Electra EMD 40 - Rating Conditions; Standard Rating Conditions; Guaranteed Operating Range

3-1
RATING CONDITIONS
Revision Y05-01Service Manual - EMD Series
3. RATING CONDITIONS
NOTES:
1. Rating conditions ISO/CD 13253R
Cooling: indoor: 27qC (80qF) DB 19qC (66q F) WB
Outdoor: 35qC (95qF) DB
Heating: indoor: 20qC (68qF) DB
Outdoor: 7qC (45qF) DB 6qC (43qF) WB
Refrigerant tubing length (one way) 7.5m (24.6 ft)
2. Guaranteed operating range:
Indoor Outdoor
Upper limit
32qC DB, 23qC WB 46qC DB
Cooling
Lower limit
21qC DB, 15qC WB 21qC DB
Upper limit
27qC DB 24qC DB, 18qC WB
-5qC DB, -6qC WB (For R22)
Heating
Lower limit
20qC DB
-9qC DB, -10qC WB (For R407C)
1 PH 198 – 242 V
Voltage
3 PH 360 – 440 V
