PRODUCT DATA SHEET
Revision Y05-01Service Manual - EMD Series
Model (Indoor & Outdoor)
EMD 60T & OU12-60T RC R407C
Installation method Ducted
Characteristics Units Cooling Heating
Btu/Hr 51860 61400
Capacity
Kw 15.2 18.0
Power input Kw 6.0 6.3
COP W/W 2.52 2.86
Power supply V/Hz/Ph 400V/50Hz/3N
Rated current A 3x16.4 3x16.8
Starting current A 74
Circuit breaker rating A 3x20
Fan type & quantity Centrifugal & 1
Fan speeds H/ M/ L RPM 1000 840 700
Air flow * H/ M/ L M³/Hr 2950 2480 2065
External static pressure Min-Max Pa 50 - 110
Sound power level ** H/ M/ L dBa 71.8 68.9 62.3
Sound pressure level *** H/ M/ L dBa 60.2 55.7 51.5
Moisture removal Lt/Hr 4.7
Condensate drain tube I.D mm 19
Dimensions W/ H / D mm 1140 400 680
Weight Kg 46
Package dimensions W/ H / D mm 1195 440 730
Package weight Kg 50
Units per pallet Units 8
INDOOR
Stacking height Units 4
Refrigerant control Capillary tube
Compressor type Scroll
Fan type & quantity Axial & 2
Fan speeds H / L RPM 825 560
Air flow H / L M³/Hr 4850 3300
Sound power level H / L dBa 70 62.0
Sound pressure level *** H / L dBa 60.4 53.7
Dimensions W/ H / D mm 900 1255 350
Weight Kg 110
Package dimensions W/ H / D mm 985 1395 435
Package weight Kg 120
Units per pallet Units 1
Stacking height Units 1
Refrigerant type R407C
Charge / Distance Kg/ M 4550 / 7.5
Additional charge per 1 meter Grams 40
Liquid line Inch 1/2
Suction line Inch 7/8
Max. tubing length Meter 50
OUTDOOR
Connections
between
units
Max. height difference Meter 25
Operation control type LCD Remote control
Heating elements Kw No
Others Crankcase heater (60W)
* Airflow in ducted units; according to nominal external static pressure.
** Sound power in ducted units is measured at air outlet side.
*** Sound pressure level is measured at 1-meter distance from the unit.
