2-11
PRODUCT DATA SHEET
Revision Y05-01Service Manual - EMD Series
Model (Indoor & Outdoor)
EMD 45T & OU10-44T RC R22
Installation method Ducted
Characteristics Units Cooling Heating
Btu/Hr 43400 45000
Capacity
Kw 12.7 13.0
Power input Kw 4.8 4.0
COP W/W 2.64 3.24
Power supply V/Hz/Ph 400V/50Hz/3N
Rated current A 3x13.1 3x11.1
Starting current A 61.8
Circuit breaker rating A 3x16
Fan type & quantity Centrifugal & 1
Fan speeds H/ M/ L RPM 1000 900 800
Air flow * H/ M/ L M³/Hr 2180 1960 1740
External static pressure Min-Max Pa 50 - 100
Sound power level ** H/ M/ L dBa 73.2 70.1 66.1
Sound pressure level *** H/ M/ L dBa 56.3 54.0 51.7
Moisture removal Lt/Hr 3.8
Condensate drain tube I.D mm 19
Dimensions W/ H / D mm 1040 400 595
Weight Kg 42
Package dimensions W/ H / D mm 1100 435 620
Package weight Kg 45
Units per pallet Units 8
INDOOR
Stacking height Units 2
Refrigerant control Capillary tube
Compressor type Scroll
Fan type & quantity Axial & 2
Fan speeds H / L RPM 1125
Air flow H / L M³/Hr 4150
Sound power level H / L dBa 65
Sound pressure level *** H / L dBa 58
Dimensions W/ H / D mm 900 970 350
Weight Kg 88.5
Package dimensions W/ H / D mm 985 1020 435
Package weight Kg 93
Units per pallet Units 6
Stacking height Units 2
Refrigerant type R22
Charge / Distance Kg/ M 2.75 / 7.5
Additional charge per 1 meter Grams 30
Liquid line Inch 3/8
Suction line Inch 3/4
Max. tubing length Meter 50
OUTDOOR
Connections
between
units
Max. height difference Meter 25
Operation control type LCD Remote control
Heating elements Kw No
Others Crankcase heater (60W)
* Airflow in ducted units; according to nominal external static pressure.
** Sound power in ducted units is measured at air outlet side.
*** Sound pressure level is measured at 1-meter distance from the unit.
