PRODUCT DATA SHEET
Revision Y05-01Service Manual - EMD Series
Model (Indoor & Outdoor)
EMD 50T & OU10-50T RC R407C
Installation method Ducted
Characteristics Units Cooling Heating
Btu/Hr 45700 51500
Capacity
Kw 13.4 15.1
Power input Kw 5.4 5.6
COP W/W 2.5 2.7
Power supply V/Hz/Ph 400V/50Hz/3N
Rated current A 3x15.0 3x15.3
Starting current A 57
Circuit breaker rating A 3x16
Fan type & quantity Centrifugal & 1
Fan speeds H/ M/ L RPM 1030 930 820
Air flow * H/ M/ L M³/Hr 2400 2160 1910
External static pressure Min-Max Pa 50 - 100
Sound power level ** H/ M/ L dBa 73.2 70.1 66.1
Sound pressure level *** H/ M/ L dBa 56.3 54.0 51.7
Moisture removal Lt/Hr 4.9
Condensate drain tube I.D mm 19
Dimensions W/ H / D mm 1040 400 595
Weight Kg 43
Package dimensions W/ H / D mm 1100 435 620
Package weight Kg 46
Units per pallet Units 8
INDOOR
Stacking height Units 2
Refrigerant control Capillary tube
Compressor type Scroll
Fan type & quantity Axial & 2
Fan speeds H / L RPM 1220 955
Air flow H / L M³/Hr 4345 3400
Sound power level H / L dBa 69 63
Sound pressure level *** H / L dBa 62 56
Dimensions W/ H / D mm 900 970 350
Weight Kg 90.5
Package dimensions W/ H / D mm 985 1020 435
Package weight Kg 95
Units per pallet Units 6
Stacking height Units 2
Refrigerant type R407C
Charge / Distance Kg/ M 4.15 / 7.5
Additional charge per 1 meter Grams 30
Liquid line Inch 3/8
Suction line Inch 3/4
Max. tubing length Meter 50
OUTDOOR
Connections
between
units
Max. height difference Meter 25
Operation control type LCD Remote control
Heating elements Kw No
Others Crankcase heater (60W), 3PH Protector
