PRODUCT DATA SHEET
Revision Y05-01Service Manual - EMD Series
Model (Indoor & Outdoor)
EMD 35 & OU8-33 RC R22
Installation method Ducted
Characteristics Units Cooling Heating
Btu/Hr 32500 34800
Capacity
Kw 9.5 10.1
Power input Kw 3.3 2.9
COP W/W 2.87 3.53
Power supply V/Hz/Ph 230V/50Hz/1PH
Rated current A 14.4 12.3
Starting current A 76
Circuit breaker rating A 20
Fan type & quantity Centrifugal & 1
Fan speeds H/ M/ L RPM 890 800 680
Air flow * H/ M/ L M³/Hr 1770 1570 1300
External static pressure Min-Max Pa 37 - 80
Sound power level ** H/ M/ L dBa 68.2 65.5 61.3
Sound pressure level *** H/ M/ L dBa 54.3 51.5 48.5
Moisture removal Lt/Hr 2.7
Condensate drain tube I.D mm 19
Dimensions W/ H / D mm 785 400 595
Weight Kg 36
Package dimensions W/ H / D mm 825 425 610
Package weight Kg 38
Units per pallet Units 8
INDOOR
Stacking height Units 4
Refrigerant control Capillary tube
Compressor type Scroll
Fan type & quantity Axial & 1
Fan speeds H / L RPM 850
Air flow H / L M³/Hr 3110
Sound power level H / L dBa 69
Sound pressure level *** H / L dBa 62
Dimensions W/ H / D mm 900 860 340
Weight Kg 78
Package dimensions W/ H / D mm 985 900 410
Package weight Kg 82
Units per pallet Units 6
Stacking height Units 2
Refrigerant type R22
Charge / Distance Kg/ M 2.33 / 7.5
Additional charge per 1 meter Grams 25
Liquid line Inch 3/8
Suction line Inch 5/8
Max. tubing length Meter 30
OUTDOOR
Connections
between
units
Max. height difference Meter 10
Operation control type LCD Remote control
Heating elements Kw No
Others Crankcase heater (60W)
* Airflow in ducted units; according to nominal external static pressure.
** Sound power in ducted units is measured at air outlet side.
*** Sound pressure level is measured at 1-meter distance from the unit.
