Display unit EN - 3
2. Operating the display unit
2.1 Safety rules
Please read all safety warnings and instructions
carefully. Failure to comply with the following
warnings may result in death or severe injuries.
Do not throw away owner’s manual or remove
any safety warning labels or instructions from
any system components. The “battery” referred
to in this manual refers to all genuine Hydrive
electric system batteries.
X Avoid distraction while riding your e-bike.
Avoid operating the display unit while riding.
X Read and follow all safety warnings and
instructions.
2.2 Product description and specifications
[P/N : 40010C18E-1 ]
1. Power button
2. Assist up button
3. Assist down button
4. Battery indicator
5. Assist level
Display
Symbol Meaning
Battery status
Full Empty
There are 5 LEDs located on the display unit which indicate the approximate level of charge of the battery pack.
Each LED indicates approximately 20% capacity. When all 5 LEDs are illuminated the battery is fully charged.
