EN - 4 Charger
2.2 Product description and specifications
[ P/N:591007 ]
Technical data
Item Specification
Input voltage
range
100 Vac – 240 Vac
Input
frequency
range
47 Hz – 63 Hz
Rated output
voltage
42 V
Output
current
2 +/- 0.2 A
Operating
temperature
32°F~104°F (0°C~+40°C) 80%RH
Storage
temperature
-4°F~131°F (-20°C~+55°C) 95%RH
Mechanical properties
Item Specification
Safety standard / Cable UL 1310
Length ( approx ) 1200 +/- 50 mm
X Clean the charger regularly. Dirt or dust
may cause electric shocks. When the
charger is unplugged from power and
disconnected from the battery use a clean
cloth to wipe any dirt or debris from the
charger and plug surfaces.
X Check the charger, cable and plug before
each use. If any damage is discovered, do
not continue use. Do not open the case of
the charger.
When the charger, charging cable or plug
is damaged, it increases the risk of electric
shock.
X Do not use the charger in flammable
environments or place the charger on
flammable surfaces (paper, cloth, etc.)
when in use. While the charger is operating,
there is potential risk of fire due to increased
surface temperature of the charger.
X Keep the battery charger out of reach of
children.
