20 Eco 3 & 4 Scooter Owner’s Manual & Service Record
Technical Specification - Eco 3 Scooter
Wheelchair type Class Class A, B or C Class B
Department of T
ransport Class Class 1 2 or 3 Class 2
Overall dimensions fully assembled length x width x height mm (in) 1000 (39) x 560 (22) x 790 (31)
Dimensions seat r
emoved tiller folded length x width x height mm (in) 1000 (39) x 560 (22) x 460 (18)
Maximum carrying capacity kg (lb) 113 (250)
Mass (weight) including batteries
kg (lb) 42 (93)
Battery voltage and capacity volts and ampere hours 12V 15Ah x 2
Mass (weight) of battery pack
kg (lb) 10 (22)
Type of seat Adjustable armrest and height
Mass (weight) of seat kg (lb) 8.7 (19.2)
Mass (weight) of front section kg (lb) 12.4 (27.2)
Mass of (weight) of rear section kg (lb) 11 (24)
Wheel size front/rear mm (in) 203 x 76 (8 x 3) / 203 x 76 (8 x 3)
Type of tyres type Solid
Maximum speed km/h (m.p.h.) 6.4 (4)
Minimum braking distance fr
om maximum speed metres 1.8
Range on full charge and flat ground km (miles) Up to 14 (9)
The turn-around width m (ft) 2.12 (7)
The maximum safe slope
degrees of slope 6˚ - Do not exceed the scooter may topple
The maximum climbing ability facing upwards degrees of slope 6˚
Ground clearance mm (in) 64 (2.5)
Maximum obstacle climbing ability mm (in) 40 (1.5)
Maximum safe descendable kerb height mm (in) 40 (1.5)
Technical Specification - Eco 4 Scooter
Wheelchair type Class Class A, B or C Class B
Department of Transport Class Class 1 2 or 3 Class 2
Overall dimensions fully assembled length x width x height mm (in) 1000 (39) x 560 (22) x 790 (31)
Dimensions seat removed tiller folded length x width x height mm (in) 1000 (39) x 560 (22) x 460 (18)
Maximum carrying capacity
kg (lb)
113 (250)
Mass (weight) including batteries kg (lb) 45 (99.4)
Battery voltage and capacity volts and ampere hours 12V 15Ah x 2
Mass (weight) of battery pack
kg (lb)
10 (22)
Type of seat Adjustable armrest and height
Mass (weight) of seat kg (lb) 8.7 (19.2)
Mass (weight) of front section kg (lb) 15.4 (33.8)
Mass of (weight) of rear section kg (lb) 11 (24)
Wheel size front/rear mm (in) 203 x 76 (8 x 3) / 203 x 76 (8 x 3)
T
ype of tyr
es
type
Solid
Maximum speed km/h (m.p.h.) 6.4 (4)
Minimum braking distance fr
om maximum speed
metres 1.8
Range on full charge and flat ground km (miles) Up to 14 (9)
The tur
n-around width m (ft) 2.56 (8.4)
The maximum safe slope degrees of slope 6˚ - Do not exceed the scooter may topple
The maximum climbing ability facing upwards degrees of slope 6˚
Ground clearance mm (in) 64 (2.5)
Maximum obstacle climbing ability mm (in) 40 (1.5)
Maximum safe descendable kerb height
mm (in)
40 (1.5)
Due to a policy of continual impr
ovement Electric Mobility Eur
o Ltd. r
eserves the right to change the specification without prior notice.
