Warning! Do not lift the rear chassis with the batteries and/or transaxle unit still fitted - back injury may result!
To transport your scooter you will need to dismantle it. Follow these instructions. Do not attempt this unless you are
c
apable of lifting the heaviest component weight applicable to your model (including accessories) as stated in the
Technical Specification Sheets. You are advised to wear gloves. (Picture numbers correspond to stages listed below).
1. Move tiller into the upright position.
2. Lift the seat off the chassis. Take care this part is heavy.
3. Remove the under-seat basket and stow.
4
. Remove the battery box by sliding it out of the rear chassis and stow it carefully in the vehicle.
5. Lift the release catch below and in front of the seat post.
6. Gently separate the front chassis from the rear. (This is a feature of the Liteway Balance Plus
model only)
7. Disconnect the Transaxle assembly from the Rear Chassis Frame by lifting the release bar at the rear.
8. Release the tiller by loosening the tiller knob.
9. Lower the tiller to the horizontal position as shown. (Note - image shown has front and rear still connected).
10. Secure the tiller by attaching the strap provided to the handlebars, taking care not to trap finger control lever.
11. Stow the chassis front and rear parts into the boot of the vehicle.
12. Stow seat in the vehicle.
13. Ensure that all parts are secure so that they cannot move while driving.
