QUICK START GUIDE
Connect the camera to the camera mount by sliding the two parts together until they click
into place. Mount the camera in the desired location in the vehicle. Connect the power
supply cable to a 12V outlet in your vehicle and to the camera mount USB port. The camera
will power on and start recording video automatically. To stop video recording press the OK
button. To restart recording, press the OK button.
PRODUCT OVERVIEW
1. HDMI Port
2. Lens
3. Speaker
4. Status Light (blue)
5. Charging light (red)
6. Menu Button
7. Microphone
8. File Protection Button
9. Mode Button
10. LCD Display
11. Up Button
12. OK Button
13. Down Button
14. Power Button
15. Holder Connector
16. Camera Button
17. USB Port
18. Reset Button
19. Micro SD Card Slot
