CONTROL PANEL
LED INDICATORS
(A) Tank full indicator light (red)
(B) Power ON indicator light (green)
(C) Settings light (green)
(D) Humidity Level and Timer 2 digit led display
(E) Timer indicator light (green)
(F) Low fan speed light (green)
(G) High speed fan light (green)
(1)
Tank full
(2)
Power On / Off Key
(3)
Humidity Control Keys (40-80% RH, incremental with 5%)
(4)
Timer settings (1-24 hrs, start/ stopping timer)
(5)
Fan Speed settings Key (Low/High)
Humidity Level & Timer 2 digit display
The led indicator performs the following functions:
1. When the unit is plugged in, it will indicate the room humidity level
2. When the humidity level is selected, it will indicate the set humidity
3. When the start / stop timer is programmed will show the set timer
Notes:
When humidity level is outside the normal operational parameters will show LO/HI
If ambient humidity is lower than 35%, it will show “LO”
If ambient humidity is higher than 95%, it will show “HI”
4
