USING YOUR BUILT-IN DOUBLE OVEN
8
ELECTRICAL CONNECTION
IMPORTANT! Electrical connection must be made by a suitable qualified person and in accordance with all
relevant local building and installation regulations.
CONNECTING THE POWER SUPPLY TERMINAL BOARD/ CONNECTOR BLOCK
• Using a screwdriver, release the tabs of the terminal board cover.
• Remove the wire clamp screw.
• Loosen the screws on the terminal block. DO NOT fully unfasten.
• Insert the wires beneath the corresponding screw heads and tighten them in position. The colour code is:
Blue = Neutral (N)
Brown = Live (L)
Yellow Green = Earth
• Fasten the cable clamp and close the cover of the terminal board.
• The power supply should be 220-240 V, 50/60 Hz, and a minimum of 2.5mm² cross sections area wire
should be used for the Live, Neutral and Earth connections.
CONNECTING THE SUPPLY CABLE TO THE MAIN CONSUMER UNIT (FUSE BOX)
An approved circuit breaker should supply the appliance with a minimum contact opening of 3 mm. The
circuit breaker should be sized according to the load, e.g., 16A, and should comply with current regulations.
The appliance requires an earth connection, and the earth wire should not be interrupted by the circuit
breaker.
The supply cable should be positioned so that it does not reach a temperature in excess of 50°c anywhere
along its length. Before connecting the power, ensure:
• Earth continuity. The electrical safety of this appliance can only be guaranteed if the cooker is correctly
installed and earthed in compliance with regulations on electrical installations.
• The electrical capacity of the system is suitable for the power of the appliance, as indicated on the data plate.
IMPORTANT! The oven must be installed to a switch that can cut all power to the appliance.
HOW TO
1. Create your desired cabinet following the dimensions and instructions provided. The cabinet must
be securely fixed to support the oven.
2. Cut out any space you need for adequate ventilation.
3. Brush away any shavings or dust to ensure this doesn’t affect the appliance.
4. You can connect the oven to the electricity supply now or after you have housed the unit depending
on your desired connection method and placement.
5. Place the oven into the cabinet and secure.
